Analog Devices ADV7850 Hardware Manual page 39

prim_mode[3:0]
Code Description
0101
HDMI-COMP
(Component Video)
0110 HDMI-GR
Graphics)
Rev. A May 2012
Processor Code
000101
000110
000111
001000
001001
001010
~
111111
CP 000000
000001
000010
CP 000011
CP 000100
CP 000101
CP 000110
000111
CP 001000
CP 001001
CP 001010
CP 001011
CP 001100
CP 001101
CP 001110
CP 001111
010000
010001
010010
CP 010011
CP 010100
CP 010101
CP 010110
CP 010111
011000
CP 011001
CP 011010
CP 011011
CP 011100
CP 011101
CP 011110
CP 011111
CP 000000
CP 000001
CP 000010
CP 000011
CP 000100
CP 000101
CP 000110
000111
CP 001000
vid_std[5:0]
Input Video Output Resolution
Reserved Reserved
Reserved Reserved
Reserved Reserved
SD 2x1 YUV 720x480i/576i
Reserved Reserved
SD 2x1 RGB 720x480i/576i
Reserved Reserved
Reserved
Reserved
SD 1x1 525i 720 x 480i
SD 1x1 625i 720 x 576i
SD 2x1 525i 720 x 480i
SD 2x1 625i 720 x 576i
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
PR 1x1 525p 720 x 480p
PR 1x1 625p 720 x 576p
PR 2x1 525p 720 x 480p
PR 2x1 625p 720 x 576p
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
HD 1x1 1280 x 720p
HD 1x1 1920 x 1080i
HD 1x1 1920 x 1035
HD 1x1 1920 x 1080
HD 1x1 1920 x 1152
Reserved Reserved
HD 2x1 720p 1280 x 720p
HD 2x1 1125i 1920 x 1080i
HD 2x1 1125 1920 x 1035
HD 2x1 1250 1920 x 1080
HD 2x1 1250 1920 x 1152
HD 1x1 1920 x 1080p
HD 1x1 1920 x 1080
SVGA 800 x 600p @ 56
SVGA 800 x 600p @ 60
SVGA 800 x 600p @ 72
SVGA 800 x 600p @ 75
SVGA 800 x 600p @ 85
SXGA 1280 x 1024p @ 60
SXGA 1280 x 1024p @ 75
Reserved Reserved
VGA 640 x 480p @ 60
39
ADV7850
Comment
YC
YPrPb
HDMI Non-Mux mode
HDMI Non-Mux Mode
