Function
sdp_c4[14:0]
0x0000 <<

6.18.5.1 CSC Manual Programming

This section outlines the settings for a conversion from NTSC YCrCb to RGB output. The CSC is only supported in these fixed settings:
94 97 00 HSync width Adjustment
94 B2 60 Disable AV codes
94 B0 00 Disable H and v blanking
94 E0 83 Manual CSC mode
94 E1 A7 CSC coefficient
94 E2 1E CSC coefficient
94 E3 91 CSC coefficient
94 E4 1D CSC coefficient
94 E5 E2 CSC coefficient
94 E6 7D CSC coefficient
94 E7 00 CSC coefficient
94 E8 03 CSC coefficient
94 E9 A7 CSC coefficient
94 EA 07 CSC coefficient
94 EB 61 CSC coefficient
94 EC 00 CSC coefficient
94 ED 00 CSC coefficient
94 EE 79 CSC coefficient
94 EF 00 CSC coefficient
94 F0 03 CSC coefficient
94 F1 A7 CSC coefficient
94 F2 00 CSC coefficient
94 F3 00 CSC coefficient
94 F4 04 CSC coefficient
94 F5 29 CSC coefficient
94 F6 79 CSC coefficient
94 F7 00 CSC coefficient
Rev. A May 2012
Description
Default
135
ADV7850
