Analog Devices ADV7850 Hardware Manual page 23

Pin No.
H7
H8
H9
H10
H11
H12
H13
H14
H15
H16
H17
H20
H21
H22
H23
J1
J2
J3
J4
J7
J8
J9
J10
J11
J12
J13
J14
J15
J16
J17
J20
J21
J22
J23
K1
K2
K3
K4
K7
K8
K9
K10
K11
K12
K13
K14
K15
K16
K17
K20
K21
K22
K23
L1
L2
L3
L4
L7
L8
Rev. A May 2012
Mnemonic Description
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
FILTA Audio Codec ADC filter capacitor
VREF_AUDIO Audio Codec block reference voltage capacitor
EP_CSB External EDID EEPROM interface
EP_SCK External EDID EEPROM interface
SHARED_EDID EDID selection signal for HDMI Port D
RESET Chip Reset. Active low. Minimum low time guarantee reset is 5 msec.
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
AC_AVDD Audio block supply (3.3V)
GND Ground
ISET Audio Codec ADC current settings
FILTD Audio Codec DAC filter capacitor
GND Ground
GND Ground
DVDDIO I/O supply (3.3V)
DVDDIO I/O supply (3.3V)
VDD Video Digital supply (1.8V)
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
AC_AVDD Audio block supply (3.3V)
AC_AVDD Audio block supply (3.3V)
AC_DACOut_R Audio Codec DAC output right channel
AC_DACOut_L Audio Codec DAC output left channel
HA_AP5 HDMI Audio port output
HA_SCLK HDMI Audio port serial clock output.
INT1 External Interrupt 1.
SDA I2C port serial data input/output pin.
VDD Video Digital supply (1.8V)
GND Ground
