19 APPENDIX D
19.1
RECOMMENDED UNUSED PIN CONFIGURATIONS
Location
Mnemonic
A1
GND
A2
GND
A3
GND
A4
RXB_2+
A5
RXB_1+
A6
RXB_0+
A7
RXB_C+
A8
ARC_B
A9
TVDD
A10
RXC_2+
A11
RXC_1+
A12
RXC_0+
A13
RXC_C+
A14
ARC_C
A15
GND
A16
RXD_2+
A17
RXD_1+
A18
RXD_0+
A19
RXD_C+
A20
ARC_D
A21
GND
A22
GND
A23
GND
B1
ARC_A
B2
HPA_A
B3
GND
B4
RXB_2-
B5
RXB_1-
B6
RXB_0-
B7
RXB_C-
B8
HPA_B
B9
TVDD
B10
RXC_2-
B11
RXC_1-
B12
RXC_0-
B13
RXC_C-
B14
HPA_C
B15
GND
B16
RXD_2-
B17
RXD_1-
B18
RXD_0-
B19
RXD_C-
B20
HPA_D
B21
GND
B22
ACMUXOUT_R
B23
ACMUXOUT_L
C1
RXA_C+
C2
RXA_C-
C3
CVDD
Rev. A May 2012
Table 108: Recommended Configuration of Unused Pins
Type
Recommended Configuration if Not Used
Ground
Ground
Ground
Ground
Ground
Ground
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Output
Float this pin
Power
This pin is always connected to Terminator supply voltage (3.3 V)
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Output
Float this pin
Ground
Ground
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Output
Float this pin
Ground
Ground
Ground
Ground
Ground
Ground
HDMI Output
Float this pin
Miscellaneous digital
Float this pin
Ground
Ground
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
Miscellaneous digital
Float this pin
Power
This pin is always connected to Terminator supply voltage (3.3 V)
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
Miscellaneous digital
Float this pin
Ground
Ground
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
Miscellaneous digital
Float this pin
Ground
Ground
Analog Audio Output
Float this pin
Analog Audio Output
Float this pin
HDMI Input
Float this pin
HDMI Input
Float this pin
Power
This pin is always connected to Comparator supply voltage (1.8 V)
441
ADV7850
