Acronym/Abbreviation
AFE
AGC
Ainfo
AKSV
An
AP
AVI
Aux
Bcaps
BGA
BKSV
CP
CSC
CSync
CTI
DCM
DDR
DDFS
DE
DID
DLL
DNR
DPP
DUT
DVI
EAV
ED
EMC
EQ
HD
HDCP
HDMI
HDTV
HPA
HPD
HQI
HSync
IC
ISRC
I 2 S
I C
2
KSV
LLC
LSB
L-PCM
Mbps
MPEG
Ms
MSB
NC
OTP
PAR
Pj'
Ri'
Rx
SA
SAV
SD
SDP
Rev. A May 2012
Description
Analog Front End
Automatic Gain Control
HDCP register. Refer to HDCP documentation.
HDCP Transmitter Key Selection Vector. Refer to HDCP documentation.
64-bit pseudo-random value generated by HDCP Cipher function of Device A
Audio Output Pin
Auxiliary Video Information
Auxiliary
HDCP register. Refer to HDCP documentation.
Ball Grid Array
HDCP Receiver Key Selection Vector. Refer to HDCP documentation.
Component Processor
Color Space Converter/Conversion
Composite Synchronization
Chroma Transient Improvement
Decimation
Double Data Rate
Direct Digital Frequency Synthesizer
Data Enable
Data Identification Word
Delay Locked Loop
Digital Noise Reduction
Data Preprocessor
Device Under Test (designate the ADV7850 unless stated otherwise)
Digital Visual Interface
End of Active Video
Enhanced Definition
Electromagnetic Compatibility
Equalizer
High Definition
High Bandwidth Digital Content Protection
High Bandwidth Multimedia Interface
High Definition Television
Hot Plug Assert
Hot Plug Detect
High Quality Input
Horizontal Synchronization
Integrated Circuit
International Standard Recording Code
Inter IC Sound
Inter Integrated Circuit
Key Selection Vector
Line Locked Clock
Least Significant Bit
Linear Pulse Coded Modulated
Megabit per Second
Moving Picture Expert Group
Millisecond
Most Significant Bit
No Connect
One Time Programmable
Parallel
HDCP Enhanced Link Verification Response. Refer to HDCP documentation.
HDCP Link verification response. Refer to HDCP documentation.
Receiver
Slave Address
Start of Active Video
Standard Definition
Standard Definition Processor
