Pin No.
L9
L10
L11
L12
L13
L14
L15
L16
L17
L20
L21
L22
L23
M1
M2
M3
M4
M7
M8
M9
M10
M11
M12
M13
M14
M15
M16
M17
M20
M21
M22
M23
N1
N2
N3
N4
N7
N8
N9
N10
N11
N12
N13
N14
N15
N16
N17
N20
N21
N22
N23
P1
P2
P3
P4
P7
P8
P9
Rev. A May 2012
Mnemonic
Description
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
AC_AVDD
Audio block supply (3.3V)
AC_AVDD
Audio block supply (3.3V)
HPOUT_R
Headphone output right channel
HPOUT_L
Headphone output left channel
HA_AP4
HDMI Audio port output
HA_AP3/INT3
HDMI Audio port output or External Interrupt pin 3. This pin can be configured as
a TTL output interrupt pin for the VDP SPI interface.
INT2
External Interrupt 2.
SCL
I2C port serial clock input.
VDD
Video Digital supply (1.8V)
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
AC_AVDD
Audio block supply (3.3V)
GND
Ground
GND
Ground
GND
Ground
HA_AP2
HDMI Audio port output
HA_AP1
HDMI Audio port output
AC_MCLK
Audio Codec/DAC clock input
AC_LRCLK
Audio DAC Left/Right clock input
VDD
Video Digital supply (1.8V)
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
GND
Ground
PVDD
DPLL supply (1.8V)
PVDD
DPLL supply (1.8V)
XTALN
Xtal output
XTALP
Xtal input or external clock input
HA_AP0
HDMI Audio port output
HA_MCLKOUT
HDMI Audio master clock output
AC_SDI
Audio DAC data input
AC_SCLK
Audio DAC SCLK input
VDD
Video Digital supply (1.8V)
GND
Ground
GND
Ground
24
ADV7850
