Analog Devices ADV7850 Hardware Manual page 164

transmitter using the following controls.
zero_spdif_in_a, IO, Address 0xAD[0]
This control is used to zero the SPDIF input to the ARC transmitter.
Function
zero_spdif_in_a
1
zero_spdif_in_b, IO, Address 0xAD[1]
This control is used to zero the SPDIF input to the ARC transmitter.
Function
zero_spdif_in_b
1
zero_spdif_in_c, IO, Address 0xAD[2]
This control is used to zero the SPDIF input to the ARC transmitter.
Function
zero_spdif_in_c
1
zero_spdif_in_d, IO, Address 0xAD[3]
This control is used to zero the SPDIF input to the ARC transmitter.
Function
zero_spdif_in_d
1
inv_spdif_in_a, IO, Address 0xAD[4]
This control is used to invert the SPDIF input to the ARC transmitter.
Function
inv_spdif_in_a
1
inv_spdif_in_b, IO, Address 0xAD[5]
This control is used to invert the SPDIF input to the ARC transmitter.
Function
inv_spdif_in_b
1
inv_spdif_in_c, IO, Address 0xAD[6]
This control is used to invert the SPDIF input to the ARC transmitter.
Rev. A May 2012
Description
Zero SPDIF input to ARC Tx channel A
Description
Zero SPDIF input to ARC Tx channel B
Description
Zero SPDIF input to ARC Tx channel C
Description
Zero SPDIF input to ARC Tx channel D
Description
Invert SPDIF input to ARC Tx channel A
Description
Invert SPDIF input to ARC Tx channel B
164
ADV7850
