Function
burst_power_act[11:0]
0xXXX
burst_power_ad[11:0], Addr 94 (SDP_IO), Address 0x46[3:0]; Address 0x47[7:0] (Read Only)
This readback displays the autodetect path burst power measurement.
Function
burst_power_ad[11:0]
0xXXX
hs_period_err_raw[11:0], Addr 94 (SDP_IO), Address 0x4A[3:0]; Address 0x4B[7:0] (Read Only)
This readback displays the raw HSync period error.
Function
hs_period_err_raw[11:0
]
0xXXX
hs_period_err_filt[11:0], Addr 94 (SDP_IO), Address 0x4C[3:0]; Address 0x4D[7:0] (Read Only)
This readback displays the filtered HSync period error.
Function
hs_period_err_filt[11:0]
0xXXX
hs_period_valid, Addr 94 (SDP_IO), Address 0x4E[0] (Read Only)
This readback displays the HSync period measurement valid flag.
Function
hs_period_valid
0
1
upd_sdp_rb, Addr 94 (SDP_IO), Address 0x4F[0] (Self-Clearing)
This control is used to update the c_gain_act, c_gain_ad, burst_power_act, burst_power_ad, hs_period_err_raw and hs_period_err_filt
readback registers.
Function
upd_sdp_rb
0 <<
1

6.5 SDP COLOR CONTROLS

The following registers provide user control over the picture appearance. They are independent of any other controls. For instance, the
brightness control is independent of the picture clamping, although both controls affect the DC level of the signal. The ADV7850 provides
10-bit control of contrast, brightness, saturation, and hue.
Rev. A May 2012
Description
Burst Power Readback value
Description
Burst Power Readback value
Description
Raw HSync readback value
Description
Filtered HSync readback value
Description
hs_period_err_filt readback invalid
hs_period_err_filt readback valid
Description
Freeze SDP multiregister readbacks
Update SDP multiregister readbacks
