Analog Devices ADV7850 Hardware Manual page 235

Function
rb_a3[12:0]
xxxxxxxxxxxxx
rb_a4[12:0], Addr 44 (CP), Address 0x0B[4:0]; Address 0x0C[7:0] (Read Only)
This readback displays the CSC coefficient A4 modified by the video adjustment block.
Function
rb_a4[12:0]
xxxxxxxxxxxxx
rb_b1[12:0], Addr 44 (CP), Address 0x17[4:0]; Address 0x18[7:0] (Read Only)
This readback displays the CSC coefficient B1 modified by the video adjustment block.
Function
rb_b1[12:0]
xxxxxxxxxxxxx
rb_b2[12:0], Addr 44 (CP), Address 0x15[1:0]; Address 0x16[7:0]; Address 0x17[7:5] (Read Only)
This readback displays the CSC coefficient B2 modified by the video adjustment block.
Function
rb_b2[12:0]
xxxxxxxxxxxxx
rb_b3[12:0], Addr 44 (CP), Address 0x14[6:0]; Address 0x15[7:2] (Read Only)
This readback displays the CSC coefficient B3 modified by the video adjustment block.
Function
rb_b3[12:0]
xxxxxxxxxxxxx
rb_b4[12:0], Addr 44 (CP), Address 0x12[4:0]; Address 0x13[7:0] (Read Only)
This readback displays the CSC coefficient B4 modified by the video adjustment block.
Function
rb_b4[12:0]
xxxxxxxxxxxxx
rb_c1[12:0], Addr 44 (CP), Address 0x1E[4:0]; Address 0x1F[7:0] (Read Only)
This readback displays the CSC coefficient C1 modified by the video adjustment block.
Function
rb_c1[12:0]
xxxxxxxxxxxxx
rb_c2[12:0], Addr 44 (CP), Address 0x1C[1:0]; Address 0x1D[7:0]; Address 0x1E[7:5] (Read Only)
This readback displays the CSC coefficient C2 modified by the video adjustment block.
Rev. A May 2012
Description
Readback value
Description
Readback value
Description
Readback value
Description
Readback value
Description
Readback value
Description
Readback value
Description
Readback value
235
ADV7850
