1 INTRODUCTION TO ADV7850 HARDWARE MANUAL

1.1 DESCRIPTION OF THE HARDWARE MANUAL

This manual provides a detailed description of the functionality and features supported by the ADV7850.

1.2 COPYRIGHT INFORMATION

© 2012 Analog Devices, Inc., ALL RIGHTS RESERVED. This document may not be reproduced in any form without prior, express
written consent from Analog Devices, Inc.

1.3 DISCLAIMER

Analog Devices, Inc. (ADI) reserves the right to change this product without prior notice. Information furnished by Analog Devices is
believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use; nor for any infringement of
patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under the patent
rights of Analog Devices, Inc.
The information contained in this document is proprietary of ADI. This document must not be made available to anybody other than the
intended recipient without the written permission of ADI.
The content of this document is believed to be correct. If any errors are found within this document or if clarification is needed, contact
the authors at DVP_VidRx@analog.com.

1.4 TRADEMARK AND SERVICE MARK NOTICE

The Analog Devices logo is a registered trademark of Analog Devices, Inc. All other brand and product names are trademarks or service
marks of their respective owners.

1.5 NUMBER NOTATIONS

Notation Description
bit N Bits are numbered in little endian format, that is, the least
significant bit of a number is referred to as bit 0
V[X:Y] Bit field representation covering bit X to Y of a value or a field V
0xNN Hexadecimal (base-16) numbers are preceded by the prefix '0x'
0bNN Binary (base-2) numbers are preceded by the prefix '0b'
NN Decimal (base-10) are represented using no additional prefixes
or suffixes

1.6 REGISTER ACCESS CONVENTIONS

Mode Description
R/W Memory location has read and write access.
R Memory location is read access only. A read always returns 0
unless specified otherwise.
W Memory location is write access only.

1.7 ACRONYMS AND ABBREVIATIONS

Acronym/Abbreviation
ACP
ADC
ADI
Rev. A May 2012
Description
Audio Content Protection
Analog to Digital Converter
Analog Devices Inc.
11
ADV7850
