Analog Devices ADV7850 Hardware Manual page 28

Pin No.
AC8
AC9
AC10
AC11
AC12
AC13
AC14
AC15
AC16
AC17
AC18
AC19
AC20
AC21
AC22
AC23
Rev. A May 2012
Mnemonic Description
CS SDRAM interface Chip Select. SDRAM CS Enables and disables the command
decoder on the RAM. One of four command signals to the external SDRAM.
CKN SDRAM interface Differential Clock Compliment Output. All address and control
output signals to the RAM should be sampled on the positive edge of CK and on
the negative edge of CKN.
CK SDRAM interface Differential Clock Right Output. All address and control output
signals to the RAM should be sampled on the positive edge of CK and on the
negative edge of CKN.
SDVDD Memory interface supply
LDQS SDRAM lower data strobe true signal
DQ1 SDRAM data line
DQ9 SDRAM data line
DQ15 SDRAM data line
DQ13 SDRAM data line
GND Ground
AVIN1 Analog video mux input channel
AVIN2 Analog video mux input channel
GND Ground
AVIN4 Analog video mux input channel
AVIN5 Analog video mux input channel
GND Ground
28
ADV7850
