Function
tri4_bilevel_slice_en
0
1 
tri5_bilevel_slice_en, AFE, Address 0x21[5]
This control is used to enable bilevel slicing on the Tri5 input.
Function
tri5_bilevel_slice_en
0
1 
tri6_bilevel_slice_en, AFE, Address 0x22[5]
This control is used to enable bilevel slicing on the Tri6 input.
Function
tri6_bilevel_slice_en
0
1 
tri7_bilevel_slice_en, AFE, Address 0x23[5]
This control is used to enable bilevel slicing on the Tri7 input.
Function
tri7_bilevel_slice_en
0
1 
tri8_bilevel_slice_en, AFE, Address 0x24[5]
This control is used to enable bilevel slicing on the Tri8 input.
Function
tri8_bilevel_slice_en
0
1 

Trilevel Slicer Readbacks

5.8.8
The input has two comparators on it for each trilevel slicer (refer to
trix_readback[1:0] registers. 'Upper level' in the following descriptions refers to trix_upper_slice_level (where x is 1 to 8). 'Lower level'
refers to trix_lower_slice_level (where x is 1 to 8).
tri1_readback[1:0], AFE, Address 0x27[7:6] (Read Only)
This readback displays Tri1 DC levels.
Rev. A May 2012
Description
Bilevel slicing
Trilevel slicing
Description
Bilevel slicing
Trilevel slicing
Description
Bilevel slicing
Trilevel slicing
Description
Bilevel slicing
Trilevel slicing
Description
Bilevel slicing
Trilevel slicing
Figure 13).The raw results of these comparators are available via the
