5 CD, DVD and USB Interchange

CD, DVD and USB interchange is used to write or recall images from a Compact Disc-
Recordable (CD-R) or Digital Versatile Disc-Recordable (DVD-R) in a Digital Imaging and
Communications in Medicine (DICOM) format. Optionally, a DICOM viewer may be stored on
the media so the images can be viewed on a personal computer.
Only CD -R or DVD -R media can be used for CD/DVD/USB Interchange. For CD-R, write
speed should be at least 4X and storage size of 700 MB. The media is write once and all
selections must be queued at the same time. Approximately 7,000 images can be stored to a
4.7 GB DVD-R.
In order to view the information placed on media using CD/DVD/USB interchange, the PC must
running Windows XP, Windows Vista, or Windows 7 operating system and containing Java 1.5
or higher versions. The first time the reader of the Interchange media tries to access the data,
the security setting in Advanced Settings on the PC must be set to "Allow active contents from
CDs to run on My Computer." A log file is created on the PC used to read the media, which
tracks the reading of the media to record issues for troubleshooting. The log file is limited to six
files and overwrites data once the limit is reached.
NOTE: CD/DVD/USB interchange is available for writing DICOM images onto the compatible
media listed in
Media and Device Requirements
The following table lists the recommended CD-R and DVD-R manufacturers that have been
qualified by GE Healthcare. Other high-quality CD-R and DVD-R media may also work, but
GEHC has qualified only the media types shown below.
Table 7: Recommended media
CD-R
Sony 650 - 700 M CD-R
Pay attention to the following declarations about media and operation requirements when you
use CDs and DVDs.
•
Only supports single layered CD-R and DVD-R media. No other media types are supported,
including but not limited to DVD-RW.
• Dual layered CD-R and DVD-R media are not supported.
•
Only supports 700 MB single layer CD-R media.
•
Only supports 4.7 GB single layer DVD-R media.
Pay attention to the following considerations about USB devices:
• USB devices can be flash drives or USB hard drives which use external power.
•
By DICOM standards, the format of USB device must be VFAT.
Chapter 17 Data Management
Table 7. It is not considered a method for long-term image storage.
DVD-R
Verbatim 4.7 GB 4X Commerical
Maxwell 4.7 GB 1X-4X
Sony 1X-4X Compatible 4G
TDK 4.7 GB Commerical
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
531
