Phases of this Series or Series of this Exam – Apply to all phases in a series selected or
all series in the exam selected.
○
All Volumes of all Exams – Apply to all volumes of all exams selected.
○
Choose Current Volume to apply to the displayed volume.
○ Choose Phases of this Series or Series of this exam to apply to all phases in a series
selected or all series in the exam selected.
○ Choose All Volumes of all exams to apply to all volumes of all exams selected.
9. Click [OK].
The Spacing between views and slice thickness can be set independently of each other
creating a gap, contiguous or overlapped images.
Number
1
2
3

7.9 Batch film images

Use this procedure to set up a batch rotation of images to film/save.
Reformat .
1. Open
2. From the Tools section, click the
3. From the Film/Save tab, click the [Batch] icon.
4. From the Batch panel, click the [Rotate] tab.
7.9.1 Rotate 360° 3D images
1. Click the appropriate arrow to indicate rotation direction.
Chapter 16 Reformat
Illustration 40: Oblique tool
Add slice handle
Tilt handle
Move handle
Film/Save tab.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Description
499
