3.
To return the image to its normal orientation, click the [Display Normal] icon
Image Display set of tools.

3.5 DICOM Gray Scale Presentation State (GSPS) objects

DICOM Gray Scale Presentation State (GSPS) is a DICOM object which saves a range of
images, WW, WL, roam, zoom, image flip and graphic annotations such as image annotation
and measurement graphics. This object is then sent to a review station along with the source
images. When the object is viewed, images are presented in the form that was displayed on the
scanner. A GSPS object can be viewed only on CT scanners or remote hosts that support
DICOM GSPS objects. Not all PACS systems support GSPS.

3.5.1 Create a GSPS object

1. In a viewport, modify the image using any of the following features:
○
Window Width and Window Level
○ Roam
○
Zoom
○ Flip
○
Rotate
○ Graphics such as ROI, measure distance, and image annotation
2. From the viewport control panel, click the arrow next to
icon
The GSPS object will be saved as series 10,000 for the current exam.

3.5.2 View a GSPS object

1. Select the GSPS object in File Manager. The images display in the Image Viewport in File
Manager.
2. Use the image tools to modify the image.
3.
To view additional GSPS objects in the series, click the Image List icon
desired GSPS from the list, then select the image view icon

3.6 Magnify or minify an image

To zoom in (magnify) or zoom out (minify) an image, right-click and drag the image in a
viewport.
Chapter 14 View Images
To reorient the image in this direction:
Rotate the image 90° to the right (clockwise)
.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Click this icon:
Export , then click the [Save State]
and select the
.
from the
391
