3.1.4.1 Protocol settings

Table 1: Protocol settings
For this setting:
Type
[Protocol] and[Manual]
Anatomy
Protocol Name
Type
[Oblique] and[Rotate]
Chapter 15 Display Applications
Illustration 10: Reformat Settings panel
1 Protocol section (opened)
2 Batch Options section (collapsed)
Direction 5480385-1EN, Revision 1
3 Output Options section (collapsed)
4 Transfer Options section (collapsed)
Select or set:
Protocol allows selecting a protocol from a anatomical category.
Manual uses a generic set of reformat parameters.
Available only when Protocol selected. Selects the anatomical
category to select a reformat protocol from. GE Reference Refo‐
mat protocols are stored in the General category.
Available only when Protocol selected.
Select the protocol.
This setting affects the settings available in the Batch Options
section.
Available only when Manual selected. Selects the model type or
generic protocol that will be applied. Two selections are available
Oblique and Rotation.
[Oblique] – Produces sagittal, coronal, or off-axis (oblique) im‐
ages from CT data.
[Rotate] – Creates multiple images of an anatomical region by ro‐
tating around a single axis at a specified angle. This is used for
vascular structures, such as pulmonary veins.
Revolution CT User Manual
423
