4 User Interface Conventions
4.1 Select items from a list
Single item
Multiple contiguous items
Multiple non-contiguous
items
4.2 Cancel
[Cancel] closes a window without executing the actions or implementing parameters described
on a window.
4.3 Button and text appearance
Buttons that are gray are inactive.
Table 2: Text Field Notifications
White Background
Underlined Text
Anchored Popover
White Background
Red Outline
116
Click the item.
Click a start point in the list, press <Shift>, click an end point in the list, and all items between start
and end are selected.
•
Press and hold <Ctrl> and click each item.
•
<Close> or <X> also closes a window without executing the actions or implementing parame‐
ters.
Illustration 26: Active Button and Inactive Button
Settings updated by the user display with a white background.
Text fields that can be changed are underlined.
Click the icon next to the parameter to open.
For updated settings that are invalid, the background is highlighted white with a red outline, and the
settings collection is flagged with an alert icon notifying the user. [Confirm Settings] is also disabled.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
4 User Interface Conventions
