Sorting The Series List; Deleting Series And Images - GE Revolution CT User Manual

The Series List sorts the series in an exam by the series number, although you can sort the
columns by any of the columns. The series types are indicated with text labels.
Table 6: Series labels
This label:
SCOUT
PROSP
COMB
SSAVE
PROC
REFMT
3D
SR
GSPS
RETRO

2.3.1 Sorting the Series List

By default, Series List sorts by series number. To sort on a different column, click the column
heading.

2.3.2 Deleting series and images

To delete a series or image, right-click the item in the Series List and then click [Delete Series]
or [Delete Image]. Alternately, you can select the item and then press the <Delete> key.
The system asks you to confirm that you want to delete the item.
516
Illustration 14: Series list
Indicates:
Scout: acquired scan data that can be viewed, W/L, measured, and so on.
Prospective: acquired scan data that can be viewed, W/L, measured, and so on.
Combined: result of a combination of image data that can be W/L. Produced by Add/Sub from images at differ‐
ent locations.
Screen Save: screen capture data that can be W/L. Produced by the Viewer, 3D, and Reformat applications.
Dose Report: generated by each exam if Dose Report is enabled on the system. CDTI
ciency displays during scan prescription and provides patient dose information.
Processed: post-processed data that can be W/L and measured. Produced by Add/Sub from images at the
same location.
Reformat: post-processed data that can be W/L, filtered, and measured.
Three-dimensional: post-processed data that can be W/L. Produced by Volume Analysis.
Structured Report: generated by each exam if Structured Dose Report is enabled on the system. A CT Dose
Report can enable tracking of dose for the patient by the hospital radiation tracking system/HIS/RIS.
Gray Scale Presentation State: produced by the Viewer to be used in conjunction with the original series to
capture presentation information (W/L, flip, rotate, zoom). It can be networked to review stations that support
this DICOM type.
Retrospective: reconstructed data post-scan.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
, DLP, and Dose Effi‐
vol
2 File Manager
