2. Type in the number of images or angle between images in the appropriate field.
Modifying one of these parameters updates the other.
3. Type in the
4. Select the desired output mode from the menu.
○
Choose Print to send generated images to the default printer (setup the Format and the
display of a Reference Image).
○
Choose Save to save generated images in a new series in the browser.
○
Choose Print/Save to film the generated images from a default printer and save them in
a new series.
5. Click [OK].
7.9.2 Radial planes on 2D views
1. From the Protocols menu, select
2. Adjust the center of radial slices (A), first radial plane location (B), and the number of radial
planes (C) on the 2D reference image.
3. Enter the Number of Images, Spacing between Images, Slice Thickness, Rendering Mode,
and FOV.
500
Illustration 41: Rotation direction
FOV .
Fan .
Illustration 42: Radial prescription
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
7 Batch Film
