3 Image Monitor

The image monitor is used to reconstruct and post-process scan data.
It is divided into the following areas:

3.1 Icons and System Status Area

This area displays the mode icon, system utilities icon, recon management icon, available disk
space, tube status icon, system messages and the date and time.
It is divided into the following areas:
108
Illustration 16: Image Monitor
Number
Icons and System Status area
1
Reconstruction and Image Processing area
2
Image Viewports
3
File Manager
4
