Confirm that the injector is connected to the system and power is on.
•
Setup the syringes.
• Prepare the Injector as described in the injector operator manual.
To set up the Enhanced Xtream Injector after the patient and the injector are prepared, follow
these steps. Review the injector status messages.
1. Prepare the injector.
2. From the Contrast collection, select
dropdown menu.
○
The button turns on and synchronizes the start of the scan and injector.
○
IV contrast is automatically turned on when Enhanced Xtream Injector is turned on.
3. Set injector settings on the
next to the Injector Settings field. The injector parameters can also be defined in Protocol
Management.
4. Click [Apply] on the
Scan Settings screen, set the scan parameters.
5. From the
6. Click [Confirm Settings].
○ If there is an alert next to the Contrast Collection, check and resolve the injector
parameters on the system or the Injector.
system and the injector are ready. Some errors may require a power cycle of the injector
to resolve.
○
Complete any required fields and note the injector status information on the
Progress screen.
7. Press [Start Scan] to start the scan and injection.
NOTE: If you have the Enhanced Xtream Injector option, after you end the exam, a
contrast report is saved as Series 996.
330
Enhanced Xtream Injector from the IV Contrast field
Injector Settings window. To open this window, click the icon
Injector Settings window when you have adjusted the settings.
NOTICE
If you stop the scan or the system aborts the scan the injector does not stop.
If you stop the injector or the injector aborts, the system does not stop
scanning.
If either of these scenarios occur, verify the remaining volume to be injected
before resuming the injection or scan. You may need to update parameters
on the Scan Settings screen.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Confirm Settings is only active when both the
4 Enhanced Xtream Injector
Scan
