GE Revolution CT User Manual page 484

Table 17: Scalpel selections
Function Name
Cut Inside
Cut Outside
Cut On Trace
Clear
Cut Depth
Undo
Keep Object
484
Illustration 30: Scalpel control panel
Click and drag around the object of interest and then click the appropriate button to either cut
inside or outside the trace. The trace may appear either red or green.
Saves the current settings as a new VR preset.
Applies the cut along the trace.
Clears the latest trace.
Allows changing the Scalpel from a restricted depth defined by the text field or an Infinite
depth.
Undoes the last operation performed. If the view on which the last operation was performed is
changed, the possibility of undoing the last operation is permanently lost.
Keeps all the voxels that are attached to the object of interest under the cursor.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Description
6 Segment
