GE Revolution CT User Manual page 404

Command / Description
pa [<start> <end>] [<rate>]
Activates cine paging. For the start and end values, enter the first and last images you want
to page thru. For rate, enter the number of images per second to page through, with the max‐
imum being 60.
pi <interval>
Allows you to set the interval for paging. The pa command must be used prior to setting pag‐
ing interval.
pm <spatial/temporal>
Allows you to change the mode for paging. Selecting temporal will display the images in a
loop mode. Spatial will display images in a back-and-forth mode.
ps
Displays first image of the previous series of the displayed exam in the selected viewport.
prop <range>
range: a= all images in series; s = series; i = image range (1-15)
For example,: prop a or prop i 1-15)
Displays selected graphics on the specified images. The "i" is lower case sensitive. In the first
example, the graphic displays on all images called into the viewport until cleared by another
command (such as erase graphics) or a different series is displayed in the viewport. In the
second example, the graphic is applied only to images 1 through 15 in the current series.
rc
Displays (reports) current mouse cursor location in pixel coordinates, and a single pixel ROI
reading.
rect
Creates a rectangle measurement cursor. Used for ROI.
ri
Puts a reference image on the selected image.
ria
Puts a reference image on all images.
rl
Rotates the image 90 degrees counterclockwise.
rmatte
Displays a rectangular, black matte or mask around the image. You can adjust the by clicking
and dragging the red open box. You can adjust the position by a clicking and dragging the
edge of the matte or the red solid box.
rr
Rotates the image 90 degrees clockwise.
rs
Reset image to initial display parameters.
scnsave
Captures the selected image exactly as it is displayed, and creates a new image with a series
number of 99 on the system disk that includes all graphics and display factors applied to the
image and/or viewport at the time of capture.
scroll <dx><dy>
Scroll images by delta x and delta y pixels.
sg
Shows, or re-displays all graphics on the selected image which were hidden with the hide
graphics command.
siw
Applies default window width and level setting to the display.
404
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Scan monitor
Scan monitor
(left), scout view‐
(left) viewport
port
X
X
X
X X
X X
X X
X X
X X
X X
X X
X X
X X
X X
5 Additional Image Tools
Image monitor
(right) patient
session viewport
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
