5. Use arrow keys to navigate between multiple pages.
6. Click [Quit].

5.3 Hide, show, or remove graphics

Use this procedure to temporarily remove added annotation and graphic objects on an image
then re-display them.
1. To hide measurements, such as ROIs:
a. From the viewport control panel, click the arrow next to
b.
Click the [Hide Graphics] icon
2. To remove measurements, select the measurement, then click the [Erase Selected
Graphics.] icon
3. To hide annotations:
a. Select the annotation you want to hide.
b.
Click [Hide Graphics] icon
c.
To remove annotations, click the[Erase all graphics] icon
400
.
or press the [Delete] button on the keyboard.
.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Measure/Annotate .
on the viewport toolbar.
5 Additional Image Tools
