Hides/Shows a vertical tick mark for all viewports.
Adds user annotation on the selected viewport.
Erase All Graphics (right-click menu), removes all the Graphics (ROIs, User Annotation,
Grid) from the selected viewport.
Flips the image left to right on the selected viewport.
Flips the image top to bottom on the selected viewport.
Rotates the image counter-clockwise by 90° on the selected viewport.
Rotates the image clock-wise by 90° on the selected viewport.
Zoom (right-click menu), selects the left mouse drag operation as zoom.
Roam (right-click menu), selects the left mouse drag operation as roam.
Window/Level (right-click menu), selects the left mouse drag operation as window/level.
Display normal (right-click menu), resets image operations on the selected viewport.
Viewer format adjusts viewport format.
Turns the window annotation off/on.
Inverts Grayscale for selected viewport.
Starts cine or movie.
Stops cine or movie.
Save to my PC Right-click menu item, exports the image of the selected viewport to the local system in
JPEG/PNG format.
Hides/Shows the Data Selector panel.
