Use The Right-Click Functions - GE Revolution CT User Manual

Table 2: Keyboard shortcuts
Indicator/Key
Film keys
Preset Window Width/Window Level Keys
Page Up / Page Down Keys
Window Width / Window Level Control
Keys
Tab
Space Bar
Ctrl Key + moving the mouse
Shift
Shift + click and drag
Alt
Alt + s

2.4 Use the right-click functions

Place the cursor over the viewport and right-click to display the on-view menu. Move the cursor
down the menu until your choice is selected. Not all choices are available under all conditions.
Table 3: Right-click menu selections
Menu Selection
Save
Display Properties
446
Description
Press <F1> - <F4> for manual filming with the
Press [F5] - [F11] for preset Window Width and Window Level.
Press these keys to scan through the images in a viewport.
Press these keys to change the WW/WL settings for images in a viewer. The Up/
Down arrow keys increase/decrease the window level, respectively. The Right/Left
arrow keys increase/decrease the window width, respectively.
Press <Tab> to swap between image control modes.
Press the <Space Bar> to show/hide the
Press <Ctrl> and simultaneously move the mouse to page through the slices.
Press <Shift> to place the cursor at the mouse location.
Press <Shift> and simultaneously click and drag to draw a trace line as you move
the mouse.
Press <Alt> and click to edit a trace area.
Press <Alt> and <s> simultaneously to save the image as you name it.
Save Image - saves the image as a DICOM image.
Save Image As - saves the image and assigns it a description.
Save Screen - saves all images displayed on the screen as DICOM images.
Hide 3D cursor - removes the 3D cursor from the screen. Toggles back with Show 3D cursor.
Reference image - displays a small reference image showing the plane orientation and position of the
current image.
Lock orientation - locks image orientation (3D and 2D oblique only). It is not possible to change the
orientation with the mouse in the locked view.
Center on cursor - centers the image on the cursor.
Center on FOV - centers the image on the FOV.
Center on object - centers the image on an object (useful after segmentation).
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Manual Film Composer .
MyTools palette.
Description
2 Reformat
