3.10.1 Mouse
1. Place the cursor over any viewport.
2. To adjust only the window's width, middle-click and drag the mouse:
○
to the right to widen the window width (make the image gray).
○
to the left to narrow the window width (make the image more black and white).
3. To adjust the window level, middle-click and drag the mouse:
○
up to darken the image.
○
down to brighten the image.
4. Middle-click and drag diagonally to change both the window width and the level.
3.10.2 Function keys
You can use the <F5> - <F11> function keys to apply preset W/L values. The W/L values are
defined from System Preferences Viewers.
1. Press one of the function keys (<F6> through <F11>) to activate the preset window.
2. Press [F5] to reset the window level to the previous setting.
Chapter 14 View Images
Illustration 13: Function keys
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
393
