5.10.2 Assign a range of colors

Color .
1. Select
Transition area, select [Step].
2. From the
3. Click and drag the colored boxes to adjust the colors to the desired value.

5.10.3 Change a color

Color .
1. Select
2. From the Active Color menu, select a color or click
3. Optional: On the color wheel, click and drag the circle to the desired color.
4. Click [Done].

5.11 Autofit

Use this procedure to refine the VR opacity in an image.
1. Display a VR image.
2.
From the VR tab, click the [VR Settings] icon
3. Place the 3D cursor on the anatomy of interest in any multi-planar view.
4. From the VR Settings panel, click [AutoFit] or press <A>.
5. Middle-click and drag the mouse up and down to refine the VR opacity.
6. Click [Save New VR Preset] to save the setting as a new VR preset.
Illustration 25: AutoFit on a vessel (top); AutoFit on the trachea (bottom)
Autofit on a vessel (top). Autofit on the trachea (bottom).
478
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
More Colors to display the color wheel.
5 Volume Render
