To remove the filter, click the [Close] icon
close the File Manager, or if you choose a different source database.

2.1.3 Source menu

When you click on a network or media device in the Source menu, the Exam List displays the
exams from the selected source. You can also access the list of network sources by clicking the
down arrow on the right of the Source menu box
Hosts window.

2.1.4 Application icons

The controls area displays application icons. The applications available depend on the options
purchased for your system.
To change the icons displayed in the control area, right-click in the control area and select the
icons you want to display. Up to seven icons can be displayed. If you choose to display more
than seven, an arrow icon
Table 1: Application icons
Icon
Chapter 17 Data Management
in the search box. The filter is also removed if you
Illustration 5: Source menu
displays indicating more choices.
Illustration 6: Control area icon selection
Description
DICOM Header — displays a listing of the image DICOM fields.
Media Creator – save DICOM images to media.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Configured Network
or by accessing the
507
