4. Select the desired output mode from the menu.
○
Choose Print to send generated images to the default printer (setup the Format and the
display of a Reference Image).
○
Choose Save to save generated images in a new series in the browser.
○
Choose Print/Save to film the generated images from a default printer and save them in
a new series.
5. Click [OK].

7.10 Save a curved parallel plane or rotating curve batch

Use this procedure to set up a Loop batch for a curved parallel plane or rotating curved batch.
Reformat .
1. Open
2. From the Tools section, click the
3. From the Film/Save tab, click the [Batch] icon.
4. From the Batch panel, click the [Loop] tab.
5. Prescribe one of the following.
○
For a curved parallel plane batch:
■ Scroll to the first image to be saved and click [Set Start].
■
Scroll to the last image to be saved and click [Set End].
○
For a rotating curved batch:
■
Adjust the angle of the first image from the Angle active annotation on the curved
viewport and click [Set Start].
■
Set the angle of the last image and click [Set End].
6. Type the number of images to be saved.
7. Press <Enter>.
8. To save the new series, set Output to Save.
9. Click [OK].
Chapter 16 Reformat
Film/Save tab.
