3.6 Set ECG Preferences

Use this procedure to set the ECG device preferences.
1. From the image monitor, click
System Preferences .
2. Click
System Preferences window, click the ECG tab.
3. From the
ECG Device area, select Internal or External .
4. In the
Internal is selected, see the Integrated Cardiac Module Operator Manual for information on
If
the settings described in 5–8 below.
Active Lead area, select Lead I , Lead II , Lead III or Auto .
5. In the
Waveform Filter area, select On or Off .
6. In the
Gain area, select 1X , 2X , 4X , 8X or Auto .
7. In the
Pacer Detect area, select On or Off .
8. In the
The following settings are for the ECG trace displayed on the scan monitor. See the
chapter for more details.
Statistics Window Length area, enter a value for seconds (0–99).
9. In the
626
Illustration 7: ECG Tab
