3.
In the Cine area, click the [Play] icon
Alternatively, make selections from the Cine area.
To do this:
Define the range of slices in the cine dis‐
play
Define the image interval
Select a viewing mode
Play the cine loop forward and backward Click the [Play] icon to play the cine
Pause the cine loop
Go to the end of the cine loop
Go to the beginning of the cine loop
Step forward through the cine loop, one
image at a time
Step backward through the cine loop,
one image at a time
NOTE: To change the series, load the new series into the viewport.

2.5 View a reference image

Use this procedure to show the image from which the primary image was prescribed in small
viewport within the image.
This is done from the command line.
•
Type ri to put on single image.
• Type ria to put on all images in the series.
384
, which uses all the default settings.
Use this setting:
Check [Play All] to play all of the images
in the series, or click [Play Range] and
enter the image numbers in the
and To fields.
Typically, leave this value set to 1 (the
default value). When displaying a multi-
phase series in cine, enter the number
representing the number of phases in
the image range.
Click the [Loop] icon to view the series
from start to end, then from start to end.
For example, if there are 20 images in
the series, the images display 1-20, 1–
20, 1-20, and so on.
Click the [Rock] icon to view the series
from start to end, and then end to start.
For example, if there are 20 images in
the series, the images display 1-20,
20-1, 1-20, and so on.
loop.
Click the [Pause] icon.
Click the [End] icon.
Click the [Beginning] icon.
Click the [Step Forward] icon.
Click the [Step Backward] icon.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Icon:
From
Loop icon
Rock icon
Play icon
Pause icon
End icon
Beginning icon
Step Forward icon
Step Backward icon
2 Image Display
