You can resize these areas in relation to one another.
Place your cursor over the line you want to move. Click and drag the line between the exam list
and the series list and the line between the series list and the images list. The images will
shrink/enlarge as the area is reduced/increased.
The system will use the new sizes the next time the drawer opens and following system restart.

2.1 Controls area

The controls area of the File Manager has a set of controls that allow you to change the source
database, search the database and launch applications.
Chapter 17 Data Management
Illustration 2: Sections of the File Manager Drawer
1 Controls area
2 Exam list
Direction 5480385-1EN, Revision 1
3 Series list
4 Image display/Image list
