Table 7: Statistics selections
Function Name
Color
Range Name
Percentages
Table 8: Configuration selections
Function Name
Min. / Max Values
Color
Range Name
Continuous Ramp
Chapter 16 Reformat
Description
Displays the color, name, and range of values assigned to each defined color. These settings can be
changed on the Configuration tab.
The percentage and area of each Volume of Interest (VOI) corresponding to each color-coded Look Up
Table (LUT) range. Areas of an image can be made to display discrete LUT values by placing an LUT
ROI on the image.
Illustration 8: Color Map Table: Configuration tab
Description
Defines the range for Min. / Max values. Type in the text field to change the values.
Click a color block to display the
color.
Defines the name of the color range. Type in the text field to change the color range name.
Displays LUT values as a continuous ramp of colors. Statistics are not available in the continuous mode.
Direction 5480385-1EN, Revision 1
New Color screen from which you can change the shade of the selected
