Menu Selection
Annotations
Trace
Mouse Modes
Enlarge
Reset Pointer
ROI
Chapter 16 Reformat
No Annotation - hides all annotations including the right and left markers.
Partial Annotation - hides or shows part of the image annotations (scan parameters).
Custom Annotation - shows the annotations that have been checked in the Annotation tab of the Dis‐
play panel.
User Graphics - shows only the user graphics (including measurements and annotations).
Full Annotation - shows all annotations. This option is available when full annotations are not shown.
When a trace has been defined with the Display Trace tool, this option is available.
Create trace - create a trace on the image.
Clear last point - deletes the last point deposited.
Clear trace - deletes all points.
Lock cursor to trace - locks the 3D cursor on the trace.
Sets the action of the left mouse button. The active mode is indicated by "->" sign.
Changes the view to Full Screen.
Returns the object back to the center of the viewport. Use this tool if there are blank viewports.
The cursor must be centered on an active ROI to view this menu.
Delete ROI - deletes the active ROI.
Delete all ROIs - deletes all ROIs.
Edit ROI's label - allows you to change the ROI's label. There is a maximum of 10 characters.
Duplicate - duplicates the active ROI.
Hide/Show Statistics - hides or shows the ROI statistics.
