7.8 Set up a batch oblique

Use Batch Oblique to define a set of oblique planes adjusting settings (range, angle, position)
from a grid on a reference image.
Reformat .
1. Open
2. From the Tools section, select the
3. From the Film/Save tab, click the [Batch] icon.
4. From the Batch panel, click the view to be used as the reference image.
Oblique tab to display a grid used to define the oblique planes.
5. Click the
6. Type a value for the Number of Images, Spacing Between Images, Slice Thickness, Mode
(Average, MIP, MIN, VR), and FOV.
7. Select the desired output mode from the menu.
○
Choose Print to send generated images to the default printer (setup the Format and the
display of a Reference Image).
○
Choose Save to save generated images in a new series in the browser.
○ Choose Print/Save to film the generated images from a default printer and save them in
a new series.
8. Select the desired Apply to mode from the menu.
○ Current Volume – Apply to the displayed volume.
498
Enter a multiple by which the FOV is changed when clicking on the red DFOV annotation. For example, if
the FOV is set to 130, the FOV is adjusted as a multiple of 130 – 6.5 mm/13 mm/26 mm. It is not possible
to set the DFOV higher than the acquired FOV or lower than a DFOV of 8 mm.
•
[Color Save (non-VR Images)] - saves non-Volume Rendered images in color.
•
[Color Save (VR Images)] - saves Volume Rendered images in color.
•
[Hide Cursor on Copies] - hides or shows the cursor on the saved or filmed image.
•
[High Definition] - films images along the Z direction in high definition.
When saving reformatted images, you can select the image type. The image type determines functions
that can be performed on the image and how the annotations are stored.
SCPT:
• Allows W/L adjustments of saved images.
• Saves only annotation (system or user entered) that is currently visible on the view. These annota‐
tions are part of the image: they can no longer be edited or deleted.
Reformatted:
•
Allows W/L adjustments, measurements, and filtering of saved images.
•
Automatically saves all system annotations with the view, even if they are hidden at the moment that
you save the image. However, the user annotations (text and measurements) are saved only if they
are shown at the moment that you save the image.
