To view annotations in a larger font, click [Customize Large Font] and select the specific
annotation group to enlarge.
NOTE: The system preset is set to
2. Click [Save] to save the new preference, or [Save and Close] to additionally close the
System Preferences window.

3.2.2 Set Window Width / Window Level Presets

Use this procedure to set W/L preset values and define shortcut keys.
Window Width/Window Level Preset area, under Name , enter anatomical names for
1. In the
each desired W/L preset.
WW and WL area, enter preset values for each anatomical name.
2. In the
3. Click [Save] to save the new preference, or [Save and Close] to additionally close the
System Preferences window.

3.2.3 Set Series Binding

Use this procedure to set the default series binding.
Series Binding area, select On or Off .
1. In the
○ On : To page through all series in an exam.
○ Off : To page through only the current series in an exam.
2. Click [Save] to save the new preference, or [Save and Close] to additionally close the
System Preferences window.

3.2.4 Set Tick Marks

Use this procedure to set default tick marks to display.
Tick Mark area, select default tick marks to display:
1. In the
Vertical & Horizontal : To show side and bottom tick marks.
○
○ Vertical : To show side only tick marks.
Horizontal : To show bottom only tick marks.
○
○ None : To show no tick marks.
2. Click [Save] to save the new preference, or [Save and Close] to additionally close the
System Preferences window.

3.2.5 Set Grid

Use this procedure to customize the default grid display.
Grid area, set the following parameters:
1. In the
Matrix Lines : Select On or Off .
a.
Line Style : Select Dotted or Solid .
b.
Chapter 20 System Management
Full Annotation .
