3. Define the
Threshold settings.
These thresholds define how the tool will categorize the patient's heart rate based on the
breath hold recording.
Variable Beat to Beat Threshold : Max beat to beat variability before the HR Rhythm is
○
classified as "Variable".
Irregular Threshold : Max number of irregular beats before the HR Rhythm is classified
○
as "Irregular".
Highly Irregular Threshold : Max number of irregular beats before the HR Rhythm is
○
classified as "Highly Irregular".
NOTE: Each cell allows you to configure an alert message, if needed. Alert messages are
read-only and cannot be edited.
4. Click [Save].

5.3 Build a cardiac protocol using Auto Gating

Use this procedure to build a cardiac protocol using Auto Gating.
Considerations
GE cardiac protocols that use Auto Gating are set to a GE defined profile. Auto Gating
automatically provides suggested settings based on the selected profile for any ECG-gated
acquisition, if an ECG recording has been done.
1. From the image monitor, click
Protocol Management .
2. Click
Protocol Selection window, click [Chest] and select an existing cardiac protocol.
3. From the
4. Click [Edit] to add Auto Gating to an existing protocol.
a. From the
Auto Gating .
b. Click
c. Select
settings.
d. Click [Apply].
Gating Based On and make sure it is set to Latest Recording .
e. Click
f. Click [Apply].
5. Continue setting the rest of the
6. Verify the remaining parameters for the subsequent series in the protocol.
7. Click [Save] or [Save As] to save the protocol.
Chapter 18 Protocols
Variable Beat to Beat Threshold , Irregular Threshold and Highly Irregular
Scan Setting window, click ECG and Gating .
On and a default profile for the exam will be used to provide Auto Gating scan
ECG and Gating parameters for the protocol.
.
