Table 1: CT System Description
638
Illustration 1: CT System Illustration
Number
1
2
3
4
5
Direction 5480385-1EN, Revision 1
Description
X-ray must reach the detector's reference
channels at the edges of the Scan Field
of View (SFOV)
X-ray Tube
Centered Patient
Gantry Opening
Detector DAS
