11 Use the Dose Audit Tool

The Dose Audit Tool provides:
•
Dose Check Log details exams which exceeded NV or AV values.
•
Protocol Summary for protocol NV values.
• Invalid Protocols are listed.
•
Export to save Dose Check Log, Protocol Summary and Invalid Protocols data to media.

11.1 Display a Dose Check Log

1. From the image monitor, click
Mode menu, click Access Controls , then Dose Audit Tool .
2. From the
Audit Tool window, click Dose Check Log .
3. From the
Log List area, select the desired log and click [OK].
4. From the
NOTE: If the log data is near the maximum size, the system posts a message to export it.

11.2 Display the Protocol Summary

1. From the image monitor, click
Mode menu, click Access Controls , then Dose Audit Tool .
2. From the
Audit Tool window, click Protocol Summary .
3. From the
A protocol summary list display.

11.3 Display the Invalid Protocols

1. From the image monitor, click
Mode menu, click Access Controls , then Dose Audit Tool .
2. From the
Audit Tool window, click Invalid Protocols .
3. From the
A list of invalid protocols display.

11.4 Export Dose Check Log, Protocol Summary, Invalid Protocols Data and User

Protocols

1. From the image monitor, click
Mode menu, click Access Controls , then Dose Audit Tool .
2. From the
3. Insert CD-R media in the DVD RW drive or insert USB media in the USB port of the media
tower.
Audit Tool window, click Export .
4. From the
Export Media area, select CD/DVD or USB .
5. In the
