2.
Click the [Advanced VR Settings] icon
Read the Advanced VR Help on the tab for more information.
3. From the VR Controls screen Active Color area, select an active color.
4.
From the Ramp area, click the [Attach Mode] icon
5. From the Active Color area, click [Attach].
6. Click and drag the colored box at the top of the ramp to adjust the opacity of the colored
voxels.
7. Repeat the steps to attach additional colors.

5.9 Cut planes

When structures of interest are hidden on a 3D or VR view, use cut planes to display them
prominently.
1. Display a VR image.
2. On a reformatted image, move the 3D cursor to the location of where you want the cut plane
reference point.
3. Right-click the
4. Rotate the view to 3D view to display structures of interest in cut area.
5. Select Cut planes off to deactivate.
476
No Cut active annotation and select a plane to cut the 3D view.
Direction 5480385-1EN, Revision 1
.
Revolution CT User Manual
5 Volume Render
