Preview the resulting batch as an animated sequence (batch loop). The controls allow you
to set the display rate (frames per second), to pause and restart the sequence, and to move
through the set step-by-step.
• Film the batch, i.e., send image set to a hardcopy device such as a laser camera. The
format (image layout on the film) is defined in the batch protocol or can be selected in the
Modify Batch panel.
•
Save the batch on the image disk of the workstation. A new series is created in the current
exam and can be used later for viewing and/or processing.

7.4 Film/Save tab

Film/Save tab contains the following selections.
The
Function Name
Batch
Movie
QTVR
Quick Export
Save Image
Save State
Save/Recall
Film/Save options

7.5 Batch screen

Film/Save tab and then click [Batch] to display the Batch screen.
Click the
Chapter 16 Reformat
Illustration 34: Film/Save tab
Creates rotation, loop or oblique batch images based on your prescription.
Creates a comprehensive movie including different rotations, zoom and pan of the volume.
Not applicable in reformat.
Exports in a single click a batch of rotations of a 3D view or a full batch of contiguous images for 2D
images.
NOTE: Video Export does not work on the Operators Console.
Saves selected image with user-selected format.
Saves current status of Volume Viewer (3D Model, displays, ROIs) as an additional series of the ex‐
am. A One-Touch protocol entitled
to restore Volume Viewer State.
Opens a clipboard where you can drag and drop objects for temporary storage within the current
Volume Viewer session.
Opens a clipboard where to drag and drop objects to store temporarily within current Volume Viewer
session.
Direction 5480385-1EN, Revision 1
Description
Save State will appear in the Application field providing the ability
