Using The Command Line; Access The Terminal Screen From The Web Ui; Access The Command Line Interface - Digi Connect IT Mini User Manual

Configuration and management

Using the command line

The Digi Connect IT Mini device provides a command-line interface that you can use to configure the
device, display status and statistics, update firmware, and manage device files.
See Command line interface
Command line reference

Access the terminal screen from the web UI

A user can log into a terminal screen and use CLI commands to access features.
1. Log in to the web
2. Click System > Terminal. The Terminal screen displays.
3. When prompted, enter your user name and password.
4. Enter the number of the port that you want to access.
5. Information about the port you are connected to displays, as well as commands.
Connecting to port5:
Settings: 9600, 8, 1, none, none
Type '~b.' to disconnect from port
Type '~b?' to list commands
6. Enter ~b? to display additional commands.
Note The ~bP, ~bO, and ~bN commands are used with the remote power management
feature. See
Command
~b.
~bB
~bc
~br
~bP
~bO
~bN
~b?
7. Enter ~b. to disconnect from the port.

Access the command line interface

You can access the Connect IT Mini command line interface using an SSH connection, a telnet
connection, or a serial connection. You can use an open-source terminal software, such as PuTTY or
Digi Connect IT® Mini User Guide
for detailed instructions on using the command line interface and see
for information on available commands.
UI.
Configure Remote Power
Description
Disconnect from the port.
Send a BREAK sequence.
Clear the history buffer.
Send a DTR reset sequence.
Cycle the outlets on this port.
Turn the power off, then on. If the power state for the outlet is
currently off, then the power is just turned on.
Power off all the outlets on this port.
Power on all the outlets on this port.
Display a list of commands.
Management.
Using the command line
30
