Services
a. Click IPv4 Addresses.
b. For Add Address, click g .
c. For Address, enter the IPv4 address or network that can access the device's web
d. Click gagain to list additional IP addresses or networks.
To limit access to specified IPv6 addresses and networks:
n
a. Click IPv6 Addresses.
b. For Add Address, click g .
c. For Address, enter the IPv6 address or network that can access the device's web
d. Click gagain to list additional IP addresses or networks.
To limit access to hosts connected through a specified interface on the Connect IT Mini
n
device:
a. Click Interfaces.
b. For Add Interface, click g .
c. For Interface, select the appropriate interface from the dropdown.
d. Click gagain to allow access through additional interfaces.
To limit access based on firewall zones:
n
a. Click Zones.
b. For Add Zone, click g .
c. For Zone, select the appropriate firewall zone from the dropdown.
d. Click gagain to allow access through additional firewall zones.
10. Repeat these steps to configure additional servers.
Configure clients
1. Click to expand Clients.
2. For Add Modbus client, type a name for the client and click g .
The new Modbus gateway server configuration is displayed.
Digi Connect IT® Mini User Guide
administration service. Allowed values are:
A single IP address or host name.
l
A network designation in CIDR notation, for example, 192.168.1.0/24.
l
any: No limit to IPv4 addresses that can access the web administration service.
l
administration service. Allowed values are:
A single IP address or host name.
l
A network designation in CIDR notation, for example, 2001:db8::/48.
l
any: No limit to IPv6 addresses that can access the web administration service.
l
See
Firewall configuration
for information about firewall zones.
Configure the Modbus gateway
314
