Interfaces
8. (Optional) To configure the IP address of a custom gateway or a custom netmask:
a. Enable the custom gateway:
(config network interface my_wwan)> modem custom_gw enable true
(config network interface my_wwan)>
b. Set the IP address and netmask of the custom gateway:
(config network interface my_wwan)> modem custom_gw gateway ip_address / netmask
(config network interface my_wwan)> modem custom_gw
To override only the gateway netmask, but not the gateway IP address, use all zeros for
the IP address. For example, 0.0.0.0./32 will use the network-provided gateway, but with
a /32 netmask.
9. Optional IPv4 configuration items:
a. IPv4 support is enabled by default. To disable:
(config network interface my_wwan)> ipv4 enable false
(config network interface my_wwan)>
b. Set the metric:
(config network interface my_wwan)> ipv4 metric num
(config network interface my_wwan)>
See
Configure WAN/WWAN priority and default route metrics
metrics.
c. Set the relative weight for default routes associated with this interface. For multiple active
interfaces with the same metric, the weight is used to load balance traffic to the
interfaces.
(config network interface my_wwan)> ipv4 weight num
(config network interface my_wwan)>
d. Set the management priority. This determines which interface will have priority for central
management activity. The interface with the highest number will be used.
(config network interface my_wwan)> ipv4 mgmt num
(config network interface my_wwan)>
e. Set the MTU:
(config network interface my_wwan)> ipv4 mtu num
(config network interface my_wwan)>
f. See
Configure SureLink active recovery to detect WAN/WWAN failures
about configuring active recovery.
10. Optional IPv6 configuration items:
a. Click IPv6 to expand.
Digi Connect IT® Mini User Guide
Wide Area Networks (WANs)
for further information about
for information
91
