Routing
6. For Interface, select the interface on the Connect IT Mini device that will be used with this
route policy.
7. (Optional) Enable Exclusive to configure the policy to drop packets that match the policy when
the gateway interface is disconnected, rather than forwarded through other interfaces.
8. For IP version, select Any, IPv4, or IPv6.
9. For Protocol, select Any, TCP, UDP, or ICMP.
If TCP or UDP is selected for Protocol, type the port numbers of the Source port and
n
Destination port, or set to any to match for any port.
If ICMP is selected for Protocol, type the ICMP type and optional code, or set to any to
n
match for any ICMP type.
10. Configure source address information:
a. Click to expand Source address.
b. For Type, select one of the following:
n
n
n
n
n
11. Configure the destination address information:
a. Click to expand Destination address.
b. For Type, select one of the following:
n
n
n
n
n
Digi Connect IT® Mini User Guide
Zone: Matches the source IP address to the selected firewall zone. See
configuration for more information about firewall zones.
Interface: Matches the source IP address to the selected interface's network
address.
IPv4 address: Matches the source IP address to the specified IP address or
network. Use the format IPv4_address[/netmask], or use any to match any IPv4
address.
IPv6 address: Matches the source IP address to the specified IP address or
network. Use the format IPv6_address[/prefix_length], or use any to match any
IPv6 address.
MAC address: Matches the source MAC address to the specified MAC address.
Zone: Matches the destination IP address to the selected firewall zone. See
Firewall configuration for more information about firewall zones.
Interface: Matches the destination IP address to the selected interface's network
address.
IPv4 address: Matches the destination IP address to the specified IP address or
network. Use the format IPv4_address/[netmask], or use any to match any IPv4
address.
IPv6 address: Matches the destination IP address to the specified IP address or
network. Use the format IPv6_address/[prefix_length], or use any to match any IPv6
address.
Domain: Matches the destination IP address to the specified domain names. To
specify domains:
i. Click to expand Domains.
ii. Click the gto add a domain.
iii. For Domain, type the domain name.
iv. Repeat to add additional domains.
IP routing
Firewall
