Parameter Descriptions

3.5 Parameters: 3-** Reference/Ramps

Parameters for reference handling, definition of limitations,
and configuration of the reaction of the frequency
converter to changes.
3 3
3.5.1 3-0* Reference Limits
3-00 Reference Range
Option:
[0] Min -
Max
[1] -Max -
+Max
3-01 Reference/Feedback Unit
Option:
[0] None
[1] %
[2] RPM
[3] Hz
[4] Nm
[5] PPM
[10] 1/min
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
60
Function:
Select the range of the reference signal and the
feedback signal. Signal values can be positive only,
or positive and negative. The minimum limit may
have a negative value, unless [1] Speed closed loop
control or [3] Process is selected in 1-00 Configu-
ration Mode.
Select the range of the reference signal and the
feedback signal. Signal values can be positive only,
or positive and negative. The minimum limit may
have a negative value, unless [1] Speed closed loop
control or [3] Process is selected in 1-00 Configu-
ration Mode.
For both positive and negative values (both
directions, relative to 4-10 Motor Speed Direction).
Function:
Select the unit to be used in Process PID Control
references and feedbacks. 1-00 Configuration
Mode must be either [3] Process or [8] Extended
PID Control.
®
VLT AutomationDrive FC 301/302 Programming Guide
3-01 Reference/Feedback Unit
Option:
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[150] lb ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
3-02 Minimum Reference
Range:
Size
related
*
MG33MH02 - Rev. 2013-09-30
Function:
Function:
[ -999999.999 - Enter the minimum reference. The
par. 3-03 minimum reference is the lowest
ReferenceFeed- value obtainable by summing all
backUnit] references.
Minimum reference is active only
when 3-00 Reference Range is set to
[0] Min.- Max.
The minimum reference unit
matches:
•
The configuration of
1-00 Configuration Mode
Configuration Mode: for [1]
Speed closed loop, RPM; for
[2] Torque, Nm.
•
The unit selected in
3-01 Reference/Feedback
Unit.
