Parameter Descriptions
2-30 Position P Start Proportional Gain
Range:
0.0500 [0.0000 - 1.0000 ]
*
2-31 Speed PID Start Proportional Gain
Range:
0.0500 [0.0000 - 1.0000 ]
*
2-32 Speed PID Start Integral Time
Range:
20.0 ms [1.0 - 20000.0 ms]
*
2-33 Speed PID Start Lowpass Filter Time
Range:
2.0 ms [0.1 - 100.0 ms]
*

2-34 Zero Speed Position P Proportional Gain

Range: Function:
NOTICE
0.0000 [0.0000 -
*
1.0000 ]
This parameter is available only
with software version 48.XX.
Enter the proportional gain for
position control at standstill in speed
mode.

3.4 Parameters: 3-** Reference/Ramps

Parameters for handling of reference, definition of
limitations, and configuration of the reaction of the
frequency converter to changes.

3.4.1 3-0* Reference Limits

3-00 Reference Range

Option: Function:
Select the range of the reference signal and the
feedback signal. Signal values can be positive only,
or positive and negative. The minimum limit may
have a negative value, unless [1] Speed closed loop
control or [3] Process is selected in
parameter 1-00 Configuration Mode.
[0] Min - Select the range of the reference signal and the
Max feedback signal. Signal values can be positive only,
or positive and negative. The minimum limit may
have a negative value, unless [1] Speed closed loop
control or [3] Process is selected in
parameter 1-00 Configuration Mode.
[1] -Max - For both positive and negative values (both
+Max directions, relative to parameter 4-10 Motor Speed
Direction).
MG33MP02
Programming Guide
3-01 Reference/Feedback Unit
Function: Option:
Function:
[0] None
[1] %
[2] RPM
Function:
[3] Hz
[4] Nm
[5] PPM
[10] 1/min
Function:
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[150] lb ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
Danfoss A/S © 10/2018 All rights reserved.
Function:
Select the unit to be used in process PID control
references and feedbacks. Parameter 1-00 Configu-
ration Mode must be either [3] Process or [8]
Extended PID Control.
