Toyota 3S-GE Repair Manual page 65

EG-51
ENGINE —- ENGINE MECHANICAL
ss'r L
3.0 mm Hcexagon/Wrench
Fulcrum \
Length 13-" Turn
1% Q
H6, 's"+,,
fir,»/f» "
Plfiqfi
2. ' 'i\
{4"\"/¢ f
<>
l (0)
ii , @
0 » ~
\\:\>'1R\/, (W i
sst '
2- M. .
SST(B) Q "' —-
P115863
vi
Q Vi
\/ /
if
J
_,,__-\
(a) Turn the No.1 idler pulley bolt to obtain the specified
torque or less, and align the holes of the pulley brack-
et and cylinder head, pass a 3.0 mm hexagon wrench
through the holes to keep the setting position of the
pulley bracket.
Torque:
69 N~m (700 kgf-cm. 51 ft-lbf)
48 N-m (490 kgf-cm. 35 ft-lbf) for SST
HINT (On vehicle):
I Use SST.
SST 09249-63010
0 Use a torque wrench with a fulcrum length of
340 mm (13.39 in.).
b Using SST, loosen the intake camshaft timing pulley
bolt.
SST 09960-10010 (09962—01000, 09963-01000)
Remove the intake camshaft timing pulley bolt.
(d) Disconnect the intake camshaft timing pulley togeth-
er with the timing belt from the camshaft, and remove
,_ '_\ the intake camshaft timing pulley.
\Z..___,_
H6864
f .
Knock Plfi
f \
§\@v'?"°/* \
,\ O» Q) .
\'
P168515
(e) Remove the knock pin from the intake camshaft.
