EG'356 ENGINE — COOLING SYSTEM
\ 2
I1 0? ' /
\,Q./
Q5?
@-
/ P055166
Ohmmeter
I .fi.
Ohmmeter O_ _I (3)
i '
No Contlnulty
_ Continuity
I __ 5
3
2
001125
Ohmmeter
Continuity 1 (b)
E'\\g{? I}
lI-- .. . I
3 ii -- 1 e G
5 Battery
2
'come
E541-l»0t
N03 Cooling No.3 Cooling Fan Relay ("FAN NO.3')
/ Fan Relav NO.3 COOLING FAN RELAY INSPECTION
1. REMOVE NO.3 COOLING FAN RELAY
2. INSPECT NO.3 COOLING FAN RELAY
A. Inspect relay continuity
Using an ohmmeter, check that there is continuity
between terminals 1 and 2.
(b) Check that there is no continuity between terminals 3
and 5.
If continuity is not as specified, replace the relay.
B. Inspect relay operation
(a) Apply battery voltage across terminals 1 and 2.
Using an ohmmeter, check that there is continuity
between terminals 3 and 5.
If operation is not as specified, replace the relay.
3. REINSTALL NO.3 COOLING FAN RELAY
